DIY JoyStick Shield Game rocker Expansion Board For Arduino

DIY JoyStick Shield Game rocker Expansion Board For Arduino

Varenummer (SKU): 1017298 Kategorier: ,

Beskrivelse

DIY JoyStick Shield Game rocker Expansion Board For Arduino

Note that this is the DIY kit, unfinished, need-it-yourself to soldering

Feature:

Model: JoyStick Shield V1
Size: 94 * 52mm
Platform: Arduino
PS2 joystick (X axis A0, Y axis A1, Z axis key D6)
Four separate buttons (D2, D3, D4, D5)
Reserve expansion interfaces: one I2C interface / a TTL serial port
Analog interface (A2-A5)
Digital Interface (D8-D13)
Arduino reset button

Fully compatible with Arduino UNO R3 interfaces
Rocker X Y-axis output is two potentiometers can be read by the AD converter twist angle
Press down on the joystick, you can trigger all the way to touch the switch to digital output
Four separate buttons, digital output, ease of use
Board marked with the port configuration of each module to facilitate debugging
Set aside the other port is not occupied, to facilitate post expansion
The expansion board can be produced by a remote controller, combined with XBee module enables wireless control
Arduino Leonardo combination can also simulate a computer mouse, etc.

Package included:

1 x DIY JoyStick Shield Game rocker Expansion Board For Arduino

Yderligere information

Vægt 0.035 g
