DIY LM386 Amplifier Speaker Kit With Clear Box Transparent Case

Description

DIY LM386 Amplifier Speaker Kit With Clear Box Transparent Case

Description:

The speaker box is kit, it need assemble all parts by yourself. (Please note before buying. We do not supply you a manual)
The box size: 101 x 78 x 76mm
Power supply: 9-12V DC

Speaker parameters:

Dimensions: diameter 52mm
Total height: 28 mm
Speaker resistance: 8 Ohm
Rated power: 2W
Maximum power capacity: 5W

LM386 amplifier kit list:

1 x PCB board
1 x 100K adjustable resistor
1 x Potentiometer knob shell
1 x Pin Header(6-pin)
2 x 4.7K resistor
1 x 10 ohm resistor
2 x 104 ceramic capacitor
1 x DIP8 IC socket
1 x LM386 IC
1 x DC005 Block
1 x 3MM LED
1 x 10UF capacitor
1 x 100UF capacitance
1 x 1000UF capacitor
1 x 3.5 Audio Block

KA2284 level indicator kit list:

1 x PCB board
2 x XH2.54-2P curved seat
2 x XH2.54-2P line
1 x 100 ohm resistor
1 x 10K resistor
1 x 2.2UF electrolytic capacitors
1 x 10UF electrolytic capacitor
1 x 103 blue white color potentiometer
1 x KA2284 chip
5 x 5MM green hair green LED
1 x 5MM red red LED
