TDA2030A Audio Power Amplifier Module Board 18W DC9-24V DIY Kit
Features:
Operating voltage: 9-24VDC (recommended DC12V, this voltage to the heat sink requirements are very low) Maximum supply voltage of this board is actually up to 40V, but you need to change the board's own electrolytic capacitor C1, the capacitor voltage value is higher than the supply voltage can be use) Total harmonic distortion: 0.08% (Po = 0.1 to 14W, RL = 4Ω) Static current: about 25mA Speaker Impedance: 4Ω-8Ω Output Power: 18W SNR: 94dB-106dB Heat: the higher voltage supply ,the greater volume, the higher the heat.
Note: This is a DIY kits, you need to have some knowledge of electronics and ability!! We don't supply any instructions, please note about this before you order it!!
TDA2030A Audio Power Amplifier Module Board 18W DC9-24V DIY Kit
Description
TDA2030A Audio Power Amplifier Module Board 18W DC9-24V DIY Kit
Features:
Operating voltage: 9-24VDC (recommended DC12V, this voltage to the heat sink requirements are very low) Maximum supply voltage of this board is actually up to 40V, but you need to change the board's own electrolytic capacitor C1, the capacitor voltage value is higher than the supply voltage can be use)
Total harmonic distortion: 0.08% (Po = 0.1 to 14W, RL = 4Ω)
Static current: about 25mA
Speaker Impedance: 4Ω-8Ω
Output Power: 18W
SNR: 94dB-106dB
Heat: the higher voltage supply ,the greater volume, the higher the heat.
Note: This is a DIY kits, you need to have some knowledge of electronics and ability!!
We don't supply any instructions, please note about this before you order it!!
Package included:
1 x TDA2030A Audio Power Amplifier Board DIY Kit
